Graco XD80 White Diesel Fuel Hose Reel, 1-1/2″ Inlet/Outlet, Part 24R563
$3,200.00
The Graco XD80 Diesel Fuel Hose Reel (Part 24R563) delivers durability and safety for demanding fuel dispensing. Built for technicians, it ensures reliable performance in heavy-duty environments. Ideal for fleet, mining, and service truck applications.
| Weight | 185 lbs |
|---|---|
| Dimensions | 31 × 31 × 31 in |
| Product Condition | New |
Available on backorder
The Graco XD80 Diesel Fuel Hose Reel (Part 24R563) is engineered for high-performance fuel dispensing in the toughest environments. Designed with a direct-drive pneumatic motor, it eliminates exposed drive chains for safer and maintenance-free operation. This makes it a reliable choice for technicians and businesses needing long-lasting performance.
Built with a heavy-duty welded spool and one-piece box frame, the XD80 reel offers superior strength compared to bolted frames. Its corrosion-resistant finish ensures long-term durability even under harsh outdoor conditions. The reel accommodates hoses up to 100 feet (30 meters) of 1-1/2 inch (38 mm) diameter, making it a perfect fit for large-scale fueling operations.
Integration is simple with the ability to adjust the inlet and motor direction for left or right-hand flow orientation. This flexibility makes installation straightforward in various fueling setups. From fleet maintenance and mining operations to agriculture and service trucks, the XD80 reel is built to perform where reliability is essential. With rugged construction and user-friendly design, it is a smart investment for improving safety, efficiency, and productivity in fuel handling.
Features & Specifications
- Direct-drive pneumatic motor eliminates exposed chains for safety
- Heavy-duty welded spool supports large-diameter hoses
- One-piece welded frame resists flexing under extreme conditions
- Powder-coated components provide superior corrosion resistance
- Supports hose capacity: 1-1/2 in. x 100 ft. (38 mm x 30 m)
- Maximum working pressure: 100 psi (6.7 bar)
- Operating temperature range: -40°F to 140°F (-40°C to 60°C)
- Overall dimensions: 30.1″ H x 30.4″ L x 31.4″ W
- Dry weight: 165 lbs (74.8 kg)
- Inlet/Outlet size: 1-1/2 in. (38 mm), NPT female threads
- Frame type: Box frame construction
- Recommended fluid: Diesel fuel
- Manufacturer’s Part Number: 24R563
