Graco XD80 Diesel Fuel Bare Reel 2″ x 50 ft – 115V Electric Motor – Yellow

The Graco XD80 Diesel Fuel Bare Reel is built for technicians who demand performance, reliability, and long service life. Designed with a heavy-duty welded frame, it’s engineered to flex under extreme operating conditions without compromising strength. Its corrosion-resistant powder-coated components ensure longevity in both indoor and outdoor environments.

With a 115V electric motor, this reel delivers consistent rewinding power for diesel fuel dispensing applications. The direct-drive motor is lubricated for life, eliminating the need for exposed chains that require maintenance and pose safety risks. You can easily change the inlet and motor direction, allowing right or left-hand flow orientation to suit your installation needs.

This reel is ideal for high-demand operations such as fleet maintenance, mining, agriculture, construction vehicle service, and public works facilities. The heavy-duty welded spool is designed to handle the weight of large hoses while protecting the drive unit from environmental damage. Built for performance and durability, the Graco XD80 helps your operation work safer, smarter, and faster.

Features & Specifications

• 2 in. (51 mm) inlet/outlet for high-volume diesel fuel transfer
• 50 ft (15 m) hose capacity for extended reach
• 115 VAC electric motor with direct-drive system
• Heavy-duty welded frame for extreme operating conditions
• Powder-coated components for superior corrosion resistance
• Adjustable inlet/motor direction for installation flexibility
• Maximum working pressure: 600 psi (41 bar)
• Operating temperature range: -40°F to 140°F (-40°C to 60°C)
• Dry weight: 179 lbs (81.2 kg)
• Color: Yellow
• Manufacturer’s Part Number: 24R571
