XD50™, Diesel Fuel, 1 in. (25 mm) Inlet, 1 in. X 100 ft. (25 mm X 30 m) Hose, NPT, Metallic Blue Part Number 24P488 Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil. Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil. Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks. Extensive Hose Offering – Standard models come complete with factory installed hoses on the reel, large selection of optional reels to fit various applications Full-Flow Swivel – Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop Rugged and Durable Body – Heavy-duty welded spool and ribbed frame for extra strength and toughness over the long haul Meets Worldwide Needs – Built standard with 90° elbow with NPT threads Technical Specifications COLOR Metallic Blue DRY WEIGHT (LB) 162 HOSE INSIDE DIAMETER (IN) 1 HOSE INSIDE DIAMETER (MM) 25.4 HOSE LENGTH (FT) 100 HOSE LENGTH (M) 30 INLET SIZE (IN) 1 INLET SIZE (MM) 25.4 INLET THREAD TYPE NPT MAXIMUM WORKING PRESSURE (PSI) 250 OUTLET SIZE (IN) 1 OUTLET SIZE (MM) 25.4 OVERALL HEIGHT (IN) 30.13 OVERALL HEIGHT (MM) 765 OVERALL LENGTH (IN) 29.4 OVERALL LENGTH (MM) 747 OVERALL WIDTH (IN) 17.47 OVERALL WIDTH (MM) 444 SERIES 50 APPLICATION Diesel Fuel TYPE Spring-Rewind Reel RECOMMENDED ENVIRONMENT Indoor, Outdoor FRAME TYPE Box Frame REEL THREAD TYPE NPT RECOMMENDED FLUID TYPE 柴油燃料, Diesel Fuel, Combustible diésel HOSE REEL TYPE Reel with Hose MODEL XD INCLUDES_HOSE Yes
